​The HDMI over Single CAT5e/6/7 Extender incorporating 2-way IR signal transfer allows for a more efficient system setup and is easy to install. Uncompressed video and audio can be transmitted to distances of up to 60 meters (1080p) or up to 35 meters (4K×2K) and supports High Definition Audio and 3D signals. Designed with HDBaseT Lite technology

(CH-514TXL, )

()

Specification
  • ​HDMI including 3D and 4K×2K (Ultra HD) support, HDCP and DVI compliant
  • Supports HDCP repeater and CEC bypass
  • Supports HDBaseT technology including 2-Way IR
  • Supports transmission distance of up to 60 meters through CAT5e/6/7 cable (1080p or 3D) or 35 meters (4K×2K)
  • Supports HDMI input up to 15 meters at 8-bit resolution or 10 meters at 12-bit resolution and output up to 15 meters at 8-bit or 12-bit resolution
  • Audio support up to LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
  • Compact size with stylish design
Inputs
1x HDMI [1x Uncompressed AV and Data]
1x 3.5mm [1x Infrared Receiver]
Outputs
1x RJ-45 [1x HDMI & Propriety Data]
1x 3.5mm [1x Infrared Emitter]
PSU:
5V/2.6A
Dimensions
55mm [W] x 82mm [D] x 22mm [H]
Net Weight
56g

SKU CH-514TXL
Model # CH-514TXL
Brand Cypress
Shipping Weight 0.5500kg
Downloads
Manual
