CHDBT-1H1CPL - 1×2 HDMI to HDMI/HDBaseT Splitter with 24V PoC

This splitter can convert a single HDMI input, 2-way IR and RS-232 control to a single CAT5e/6/7 output and includes a simultaneous HDMI bypass output. It supports resolutions up to 1080p Full HD, 4K×2K timing, 3D and multi-channel digital audio formats (such as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio). The HDMI bypass output can be connected to an HDMI display or cascaded to another splitter. The CAT5e/6/7 output can be connected to a CAT5e/6/7 to HDMI Receiver to extend the operating distance up to 60 meters with 24V POC (Power over Cable) feature.

(CHDBT-1H1CPL, )

()

Specification

HDMI with 3D & 4K2K supported, HDCP and DVI compliant
Simultaneous HDMI and CAT5e/6/7 outputs
Supports data rate from 250Mbps up to 3Gbps
Supports wide range of PC resolutions from VGA to WUXGA and HDTV resolutions up to 4K2K (3840x2160@24/25/30Hz & 50/60 YUV_420 and 4096x2160@24Hz & 50/60 YUV_420)
Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission (32-192kHz sample rate)
Supports distances up to 60 meters through CAT5e/6/7 cables
Supports USB service port
Supports Bidirectional IR control
The 3D signal display follow by display TV’s EDID

Inputs	1x HDMI [1x Uncompressed AV and Data] 1x 3.5mm [1x Infrared Receiver] 1x 3.5mm [1x RS-232] 1x USB Mini-B [1x SERVICE Propriety Data]
Outputs	1x HDMI [1x Uncompressed AV and Data] 1x RJ-45 [1x HDMI & Propriety Data] 1x 3.5mm [1x Infrared Emitter]
PSU:	24V/1.25A
Dimensions	102mm [W] x 110mm [D] x 25mm [H]
Net Weight	252g
